MIL-PRF-8622C
TABLE III. Sample size, acceptance criteria, examinations, and tests of the valve.
Inspection
Method
Sample size
Acceptance criteria
Visual Examination
Every valve for critical
An acceptable quality level to
(see Table IV for
4.5.1.1
defects
be determined by the
classification
Inspection level for minor
acquisition activity
of defects )
defects to be determined by
the acquisition activities
Dimensions
4.5.1.1.1 Inspection level to be
Acceptable quality level to be
determined by the
determined by the acquisition
acquisition activity
activity
Leakage
4.5.2
Every valve
Acceptable quality level to be
determined by the acquisition
activity
Pressure drop
4.5.3
Every valve
Acceptable quality level to be
determined by the acquisition
activity
Proof pressure
4.5.4
Every valve
Acceptable quality level to be
determined by the acquisition
activity
Opening
4.5.9.1
Every valve
Acceptable quality level to be
determined by the acquisition
activity
Identification of
4.5.1.1.2
Every valve
Acceptable quality level to be
product
determined by the acquisition
activity
Oxygen purge
4.5.13.2
Every valve
Acceptable quality level to be
determined by the acquisition
activity
4.4.2 Temperature and pressure. Unless otherwise specified (see 6.2), tests shall be conducted at
local ambient temperature and barometric pressure. The temperature and barometric pressure
shall be recorded at the time of inspection. This information shall be available for computation of
test data, where required, at normal temperature and pressure (NTP) condition. NTP conditions
are 70 0F (21.1 0C) and 29.2 inches of mercury (101.3 kPa). Test instruments shall be calibrated
or adjusted according to their required usage in conducting individual tests.
4.5 Inspection methods.
4.5.1 Visual examination.
9
