MS28766B
TABLE II. Bolt, valve dimensions - Continued.
Dash No |
M + .0004 |
N |
p + .031 |
R |
u + .062 |
v + .062 |
-4 |
.4989 |
.425 |
.688 |
2.332 |
1.750 |
- |
-6 |
.4989 |
.425 |
.875 |
2.431 |
1.812 |
.750 |
-8 |
.8114 |
.738 |
1.000 |
2.782 |
2.125 |
- |
-10 |
.8114 |
.738 |
1.125 |
2.883 |
2.188 |
.938 |
4. Nut, valve detail design and dimensions
4.1 Nut, valve design and configuration. The design and configuration of the nut of the valve shall be in accordance with figure 4.
FIGuRE 4. Nut, valve detail design.
7
