Note:
1. 0-ring application.
MS28766B
For MS28766 -4 and -6 valves, use part number SAE-AS28775-112 0-ring. For MS28766 -8 and -10 valves, use part number SAE-AS28775-211 0-ring.
2. Body, valve detail design and dimensions.
2.1 Body, valve design and configuration. The design and configuration of the body of the valve shall be in accordance with figure 2.
Body front view
FIGURE 2. Body, valve design and configuration.
