MIL-DTL-3155 Valve, Temperature-Regulating Ventilation Heater, Steam Control, Naval Shipboard UseThis specification covers thermostatic-controlled steam valves for temperature regulation of shipboard ventilation heaters. These valves are of the self-operated type, requiring no separate power source such as electricity or compressed air.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11


MIL-DTL-3155D(SH)
Dimensions in inches
Dimensions in inches (maximum)
Model and size
Model and size
(maximum)
number
number
A
B
C
A
4⅞
E-½
2
3
D-21
6½
4⅞
E-1
2
3
D-22
6½
E-2
6
3
4
D-23
6½
6⅛
E-3
6
3
4
D-24
63/8
6⅛
E-4
3
4
D-25
63/8
E-5
3
4
D-26
7
63/8
E-6
3
4
D-27
7
61/16
E-7
3
4
D-28
7½
61/16
E-8
3
4
D-29
7½
E-9
6½
3
4
E-10
6½
3
4
E-11
7
3
5
E-12
7
3
5
FIGURE 1. Valve dimensions.
