MIL-DTL-27166F
TABLE I. First article inspection.
Characteristic
Requirement
Test
Performance
3.6
4.6
Reseal
3.6.1
4.6.1.2
Leakage
3.6.1.1
4.6.1.2
Cracking
3.6.2
4.6.1.2
Minimum flow rate
3.6.3
4.6.1.2
Operating life
3.6.4
4.6.2
Environmental
3.6.5
4.6.3
High temperature
3.6.5.1
4.6.3.1
Low temperature
3.6.5.1
4.6.3.2
Humidity
3.6.5.2
4.6.3.3
Vibration
3.6.5.3
4.6.3.4
Sand and dust
3.6.5.4
4.6.3.5
Rough handling
3.6.5.5
4.6.3.6
Salt fog
3.6.5.6
4.6.3.7
4.3.1 First article samples.
The first article test samples shall consist of three valves of each manufacturer's part number to
be tested and shall be representative of the production valves. For valves employing filters (see
3.5.2), the filters shall be used during all tests to which the valve is subjected. The contractor
shall be required to retest every three (3) years as a minimum; otherwise, the first article tests
cannot be waived (see 6.2 and 6.5.1).
4.3.2 Test sequence.
The three test samples shall be subjected to the following specified tests:
SAMPLE VALVE 1
SAMPLE VALVE 2
SAMPLE VALVE 3
a.
Cycling, cracking, reseal,
a.
Cycling, cracking, reseal,
a. Cycling, cracking,
leakage, flow rate (4.6.1)
leakage, flow rate (4.6.1)
reseal, leakage,
flow rate (4.6.1)
b.
Humidity (4.6.3.3)
b.
High temperature (4.6.3.1)
b.
Rough handling (4.6.3.6)
c.
Salt Fog (4.6.3.7)
c.
Low temperature (4.6.3.2)
c.
Vibration (4.6.3.4)
d.
Cracking, reseal,
d.
Sand and dust (4.6.3.5)
d.
Operating life (4.6.2)
leakage, flow rate
(4.6.1.2)
e.
Cracking, reseal, leakage,
e.
Cracking, reseal, leakage,
flow rate (4.6.1.2)
flow rate (4.6.1.2)
8
