MIL-DTL-23450D
TABLE III. R-12 and R-22 valve characteristics.
R-12 valves
Notes
Type I
These valves are:
MS17982-1
a. Primarily for use in military standard refrigeration systems using military
MS17982-2
standard fractional horsepower hermetic compressors.
b. Internally equalized.
These valves incorporate a pressure limit means that limits the suction
pressure to a pre-set maximum.
Pressure limiting means is required.
Type II
These valves are:
MS17982-3
a. For use in military standard refrigeration systems using military standard open
MS17982-4
type and integral horsepower hermetic compressors.
MS17982-5
b. Externally equalized and should be used with multi-circuit evaporators fed
through a refrigerant distributor.
Type II
These valves are:
MS17982-6
a. For use in military standard air conditioning systems and high
MS17982-7
temperature refrigeration systems using military standard open type
MS17982-8
and integral horsepower hermetic compressors.
MS17982-9
b. Externally equalized and should be used with multi-circuit evaporators fed
MS17982-10
through a refrigerant distributor.
MS17982-11
MS17982-12
R-22 valves
Notes
Type I
These valves are:
MS17982-13
a. Primarily for use in military standard refrigeration systems using military
MS17982-14
standard fractional horsepower hermetic compressors.
b. Internally equalized.
Type II
These valves are:
MS17982-15
a. For use in military standard refrigeration systems using military standard open
MS17982-16
type and integral horsepower hermetic compressors.
MS17982-17
b. Externally equalized and should be used with multi-circuit evaporators fed
through a refrigerant distributor.
Type II
These valves are:
MS17982-18
a. For use in military standard air conditioning systems and high
MS17982-19
temperature refrigeration systems using military standard open type
MS17982-20
and integral horsepower hermetic compressors.
MS17982-21
b. Externally equalized and should be used with multi-circuit evaporators fed
MS17982-22
through a refrigerant distributor.
MS17982-23
MS17982-24
6.2 Acquisition requirements should specify the following:
a. Title, number, and date of this specification.
b. Title, number, and date of the applicable specification sheet and the complete PIN (see 3.1).
c. Type, style, size, refrigerant, and capacity required (see 1.2).
d. Inspection requirements if other than specified (see 4.1).
e. First article when required (3.2 and 4.2).
f. Packaging requirements (see 5.1).
9
