INCH-POUND
MIL-DTL-19068B
8 August 2006
SUPERSEDING
MIL-V-19068A(ASG)
20 August 1955
DETAIL SPECIFICATION
VALVES, SHUTTLE, HYDRAULIC, AIRCRAFT, TYPE II SYSTEMS
INACTIVE FOR NEW DESIGN AFTER 25 AUGUST 1998
This specification is approved for use by all Departments and Agencies of the
Department of Defense.
1. SCOPE
1.1 Scope. This specification covers shuttle valves for use in aircraft hydraulic systems
o
operating at 3000 psi pressure and temperature range from -65 to +275 F.
1.2 Classification. Shuttle valves are furnished of the following types (see 6.2).
Type I
-
Direct Mounting (MS28766-Valve)
Type II
-
Internal-Thread, Tube Fitting Outlet (MS28767-Valve)
Comments, suggestions, or questions on this document should be addressed to the
Commander, Naval Air Warfare Center Aircraft Division, Code 491000B120-3, Highway
547, Lakehurst, NJ 08733-5100 or emailed to 4Hthomas.omara@navy.mil. Since contact
information can change, you may want to verify the currency of this address information
using the Assist Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 4820
